HS-VT chain wrench hoist introduction
HS-VT series wrench hoist has the function of quickly adjusting the position of the hook, novel shape, unique style, beautiful body, good braking performance, higher work efficiency. Widely used in wharf, mining, shipbuilding, construction, transportation, post and telecommunications and other departments of equipment installation, lifting, machinery traction, parts binding, wire tension and welding, and other occasions.
HS-VT chain wrench picture display
Repair and maintenance of chain wrench
1. The internal parts should be cleaned and lubricated according to the usage. If the machine fouling more, should be taken apart, cleaning and lubrication, lest the movement is blocked and affect the use, after each project should be carried out 1 cleaning and maintenance.
2, daily maintenance, can all the body into the kerosene tank, soak for several minutes and shake a few times, will drain the dirty oil, drop a few drops of oil in the movement can be.
3. After the machine is disassembled and cleaned, it must be installed in its original position, checked and confirmed to be normal before continuing to use.
4. Do not disassemble rivets.
5. When the clamp is disassembled and reassembled, the length and direction of the clamp must be assembled according to the structure drawing.
6. Disassembly and maintenance must be carried out by skilled workers with maintenance experience and mechanical knowledge.
How it works
The hand chain hoist rotates by pulling the manual chain and the hand chain wheel to press the friction ratchet and the brake seat into an integral body to rotate together, and the tooth long shaft rotates the tooth short shaft and the spline hole gear. In this way, the lifting sprocket of the device on the spline hole gear drives the lifting chain so as to lift the heavy objects smoothly. Ratchet friction disc type one-way brake, under the load can be self-braking, under the role of the spring pawl and Ratchet mesh, the brake work safely. If you need to know more you can consult Liam. They are professional in this field.
